SavkoLock Mechanical Gangway Lockdown
A purpose-built feature that positively locks gangways in place, guaranteeing reliable protection and total confidence.
How SavkoLock Works
SavkoLock automatically locks down the gangway in the lowered (deployed) position. While the gangway is locked down, it cannot be lifted, shifted, or adjusted—keeping the safety cage securely in place over the vehicle and keeping the worker/operator from falling.
A foot pedal located on the platform side of the gangway releases the lock. Because the pedal is on the platform—not on the vehicle—a worker standing on top of the vehicle cannot unlock or move the gangway. The gangway stays locked until the worker has returned safely to the platform.
Why It Matters
- Prevents gangway/safety cage from being unexpectedly lifted while a worker is on the vehicle
- Eliminates dangerous gaps between the platform and vehicle
- Required in many industries, where gangway movement during access is a known hazard
- Meets positive-lock safety requirements with a simple, all-mechanical system
- In-stock, ready to ship
Savkolock
Safety & Compliance Expert
HAVE A QUESTION?
Talk to a Safety Expert Now
Interchangeable with our previous SafeLok solution
Engineered for the toughest conditions
Our new all-mechanical design performs flawlessly in cold climates—guaranteeing reliable protection and total confidence.
Includes:
- Patent-pending locking device
- T Frame support structure and mounting brackets
- Cabling and connections
- Protective covers
SavkoLock: a name rooted in protection, delivering a positive-lock gangway safety system that stops unexpected lift and dangerous gaps.
SavkoLock reflects SafeRack’s commitment to partnership and protection, drawing its name from the meaning of “protector” in the family name of our Canadian partner, Rob Sawchuk (Savko). In recognition of Rob’s leadership and dedication to keeping operators safe on every gangway, SafeRack combined “Savko” with “Lock” to signify a purpose-built device that positively locks gangways in place, helping prevent sudden movement, unsafe gaps, and dangerous falls.
SavkoLock Assembly for 24″ G4 Gangway
#222759
- Prevents lifting of the gangway system from the vehicle being accessed
- Allow free deployment of gangway
- ONLY for use on SafeRack G4 standard 24″ wide gangways (3-step thru 7-step models)
- Depress & hold of foot pedal releases mechanism for elevation to normal stored position
- Purchase with New G4 Gangway or Retrofit to Existing G4 Gangway
- Ambient operating temperatures down to -40 degrees F
SavkoLock Assembly for 36″ G4 Gangway
#222760
- Prevents lifting of the gangway system from the vehicle being accessed
- Allow free deployment of gangway
- ONLY for use on SafeRack G4 standard 36″ wide gangways (3-step thru 7-step models)
- Depress & hold of foot pedal releases mechanism for elevation to normal stored position
- Purchase with New G4 Gangway or Retrofit to Existing G4 Gangway
- Ambient operating temperatures down to -40 degrees F
SavkoLock Assembly for 48″ G4 Gangway
#222762
- Prevents lifting of the gangway system from the vehicle being accessed
- Allow free deployment of gangway
- ONLY for use on SafeRack G4 standard 48″ wide gangways (3-step thru 7-step models)
- Depress & hold of foot pedal releases mechanism for elevation to normal stored position
- Purchase with New G4 Gangway or Retrofit to Existing G4 Gangway
- Ambient operating temperatures down to -40 degrees F
Replacement SavkoLock
#220750
- Mechanical lock, cabling, and connections
- Rod bellow protection
- Protective outer cover
- Ambient operating temperatures down to -40 degrees F/C
- Attaches to EXISTING T-Frame support structure and gangway
Telescoping Ramp
The FRT (Flat Ramp Telescoping) is designed for railcar applications, featuring a slip-resistant walking surface and a telescoping extension to eliminate gaps. Models are available with telescoping top handrails when not equipped with a safety cage.
Built on our redesigned
- Order and install in weeks, not months
- Longest service life in industry
- Modular – Upgrade/repair in field
Vehicles
Attributes
Telescoping extension to adjust for railcar crash boxes or applications that don’t require safety cage
Options
Safety Cage
Material
Aluminum with stainless steel hardware
Stainless steel
Galvanized available.
Load
500lbs
Gangway
200lb
Handrail
Widths
24 to 72 inches.
Custom & wider options are available
Reach
Range from 37 to 89 inches with an 11 or 21 inch extension
Talk to a Safety Expert Now
Self-Adjusting
Built to articulate and self-level, SafeRack’s self-adjusting stair gangways accommodate different vehicle heights. Trust our team of experts to determine which gangway size best suits your needs.
Built on our redesigned
- Order and install in weeks, not months
- Longest service life in industry
- Modular – Upgrade/repair in field
Vehicles
Attributes
Easily adjusts to different vehicle heights
85° Working Range
Options
Safety Cage
Material
Aluminum with stainless steel hardware
Load
500lbs
Gangway
200lb Handrail
Widths
24”, 36”, 48”, 60” and 72”.
Custom & wider options are available.
Reach
3 to 7 steps and can reach up to 101.5 inches in length
Talk to a Safety Expert Now
Flat Ramp Style
The SFR gangway is a flat ramp design with a slip-resistant surface, ideal for hopper cars and some trucks when platform and vehicle heights are similar, featuring rubber bumpers, machine-quality pivot points, and a hot-dipped galvanized steel base tread.
Built on our redesigned
- Order and install in weeks, not months
- Longest service life in industry
- Modular – Upgrade/repair in field
Vehicles
Attributes
Easily adjusts to different vehicle heights
Options
Safety Cage
Material
Aluminum with stainless steel hardware
Stainless steel
Galvanized available.
Load
500lbs
Gangway
200lb
Handrail
Widths
24 to 72 inches.
Custom & wider options are available
Reach
range from 36 to 88 inches
Talk to a Safety Expert Now
Gangway Safety Cages
2-Rail Safety Cage
Finish Options
Mill Finish
Hi-viz Orange
Applications
Railcar top loading
sits on top of crashbox
4-Rail Safety Cage
Finish Options
Mill Finish
Hi-viz Orange
Applications
Access top of tank trucks
ISO Container Cage
Finish Options
Mill Finish
Hi-viz Orange
Applications
Access to ISO containers
SuperMaxx Safety Cage
Finish Options
Mill Finish
Hi-viz Orange
Applications
Versatile use. Ideal for hopper trailers
FracSand Cage
Finish Options
Mill Finish
Hi-viz Orange
Applications
Access proppant containers
Custom Safety Cages
We can design a custom cage to suit any loading and access application
Applications
